AC power supply
EAC-SP
VOLTAGE: UP TO 700VAC / 1000VDC per phase | CURRENT: UP TO 2000A per phase | POWER: UP TO 12kVA
The electronically controllable AC-Source EAC-SP have a switching power supply at the input and a linear power amplifier on the secondary side. The devices are used to simulate voltages, currents, frequencies and waveforms independently of the mains, 1-phase.
Power from 250VA to 12kVA
Output voltage up to 700VAC / 1000VDC
Output current up to 2000A
Output frequency up to 2000Hz
Indication via graphic display
Linear regulated power amplifier, distortion factor at Pmax: 0.15%
