AC power supply
EAC-3SP
VOLTAGE: UP TO 700VAC / 1000VDC per phase | CURRENT: UP TO 2000A per phase | POWER: UP TO 36kVA
The electronically controllable AC-Source EAC-3SP have a switch mode power supply at the input and a linear output stage on the secondary side. The devices are used to simulate voltages, currents, frequencies and waveforms independently of the mains, 3-phase.
Power from 750W bis 36kW
Output voltage up to 700 VAC/phase-phase/ 1000 VDC
Output current up to 2000 A per phase
Output frequency up to 2000 Hz
Indication via graphic display
Linear regulated power amplifier, distortion factor at Pmax: 0.15%
